Home / All / Compressor Oil Filters / For Ingersoll Rand / Screw Compressor Oil Filter Element OEM Supplier | Compressor Lube Filter 24121212

Screw Compressor Oil Filter Element OEM Supplier | Compressor Lube Filter 24121212

Model
24121212

Detail Information

Element Type:Compressor oil filter element
Filter Media:Imported pleated filter paper (cellulose / glass-fiber blend)
Filtration Precision:10–25 µm
Initial Pressure Drop:≤ 0.02 MPa
Service Life:Up to 2,000 h (oil quality / temperature dependent)
End Caps:Polymer, color-coded (red top / red bottom)
Center Tube:Stainless steel (corrosion-resistant, high collapse strength)
Sealing Gaskets:NBR
MOQ:1 piece
HS Code:8421.2390

Product Overview

Screw compressor lube oil filter element: high dirt-holding capacity, 10–25 µm, 2,000 h life. Factory-direct.

Direct OEM Compatible Drop-in Fit Color-Coded Caps Factory-Direct Compressor Oil Filter Element for Screw Compressors Compatible cartridge 24121212 for Ingersoll Rand rotary screw air compressors. Captures wear particles and sludge, extends oil life, and protects bearings and rotors with OEM-matched fit. Part No.

Where it fits

Built as a direct drop-in compatible element for rotary screw air compressors (oil circuit). Send us your compressor make, model and current part number and we will confirm the correct match before you order.

Technical Specifications

Filter Type	Compressor oil filter element
Model / Part No.	24121212
Brand	AIRPULL
Filter Media	Imported pleated filter paper (cellulose / glass-fiber blend)
Filtration Precision	10–25 µm
Initial Pressure Drop	≤ 0.02 MPa
Service Life	Up to 2,000 h (oil quality / temperature dependent)
End Caps	Polymer, color-coded (red top / red bottom)
Center Tube	Stainless steel (corrosion-resistant, high collapse strength)
Sealing Gaskets	NBR
MOQ	1 piece
HS Code	8421.2390
Country of Origin	China (Xinxiang, Henan)

Part Number Support

Support compatible according to part number or drawing

24121212

1604039380

1604132802

1094319500

1830051911

1202804092

1202804002

1092200288

1604132880

1092200281

1604038300

1202641400

1604253380

1092200283

1092203406

1071092000

Didn't find your part number? Send us the compressor model or serial number — we'll check compatibility and reply within 24 hours.

Disclaimer

AIRPULL compatible filter elements are aftermarket components manufactured to meet or exceed the dimensional and performance specifications of the referenced OEM parts. All referenced part numbers and drawings are listed for cross-reference and compatibility identification only. AIRPULL is not affiliated with any original equipment manufacturer. Brand names, trademarks and part numbers shown on this page are the property of their respective owners. Please confirm fitment against your compressor model and serial number before ordering.
